Vacuum Casting is a widely used process in rapid prototyping, typically used for building 10 to 50 pieces of functional prototypes out of broad range of polyurethanes and other polymers.

Vowin  prototype owns 3 sets of vacuum casting machines, which can cast prototypes with the max dimension up to 2200mm*1200mm

*1000mm. We can accurately reproduce the prototypes with original color, over-mold, texture and geometries from the master model and components. These plastic castings will closely represent the mechanical properties of the intended production parts from a steel mold. One silicone mold can cast about 15 to 20 pieces of parts, depends on complexity, painting or original color, size and other factors in different parts. The typical lead time is 7 working days for 10 parts.




Vacuum Casting Material Including:


Transparent PU, Soft plastic PU, ABS PU, PP/PE PU, Polycarbonate PU. We purchase PU material from Hei-Cast company, Axson and BJB company.





Vacuum casting polyurethanes resins

Material Material simulation Supplier Strenght Shore Product color description Advantage Disadvantage Comment & Compare to Other material
ABS TYPE
PU8150 ABS Hei-CAST 83 shD Amber,White and Black Good resistance Can plus pigement for any color
PX-215 ABS Axson 65-74 shD White/black Good resistance Can plus pigement for any color
PX-100 ABS Axson 65-74 shD White/black Good resistance Can plus pigement for any color
PX 1180 ABS Axson Shore(75) D1 White/black Ideal Can plus pigement for any color
UP4280 ABS Axson 81 shD White/black Ideal Can plus pigement for any color
POLYPRO TYPE
UP5690 PP Axson 75-83 shD White / Black Good resistance Can plus pigement for any color
PU8570 PP Hei-CAST 83 shD Black/transparent with yellow/black Good resistance Can plus pigement for any color
8550 PE&PP Hei-CAST 76 shD White/black   Can plus pigement for any color
COLORABLE ELASTOMERS
PU8400 Rubber/Elastomer Hei-CAST 20-90 shA Milky white /Black Good bend Can plus pigement for any color
T0387 Rubber/Elastomer Hei-CAST 30-90 shA Clear/black Good bend Can plus pigement for any color
HIGH TEMPERATURE
PX223HT PS/ABS Hei-CAST 80 shD Black Ideal TG 120° Only black,cant change any color except for black
PU8098 PC Hei-CAST 85 shD White/Black High T°C 105° 2nd source for PC
UP6160 ABS Axson 80–81 shD half-transparent Good resistance Can plus pigement for any color
UL-VO
PU8263 ABS Hei-CAST 83 shD White/black Good resistance Can plus pigement for any color
PU8260 ABS Hei-CAST 83 shD White/black 94V0 flame retarding Can plus pigement for any color
CLEAR
UPX5210 PMMA/Acrylic Axson 87 shD Clear Coloration TG100° Can plus pigement for any color
X522HT PMMA/Acrylic Axson 87 shD Clear Coloration TG100° Supplier stop production
PX5210HT PMMA/Acrylic Axson 87 shD Clear Coloration TG100° Can plus pigement for any color
PX510 PC China 80 shD Clear Ideal TG 65° Can plus pigement for any color
